MOZA SR-P Pedals ( Throttle and Brake Pedal ) (No Clutch- Sold Separately)
Original price was: ₹19,999.00.₹16,299.00Current price is: ₹16,299.00.
MOZA SR-P Two Pedals Throttle and Brake Pedal (No Clutch- Sold Separately)
Feature
- Universal Racing Pedals for PC: The MOZA SR-P pedal set of 2 includes a brake pedal and an accelerator pedal. Simply connect it with PC through USB. Its universal compatibility with all sim racing gear ensures a smooth and hassle-free experience for all racing enthusiasts
- Solid Driving Simulator Pedals: The pedal is machined with high-strength steel giving superior quality, engineered to withstand intense racing sessions, ensuring longevity and reliability
- Floor Mounted Organ Type Accelerator Pedal: The organ-type accelerator pedal allows the driver’s foot and pedal to follow the same trajectory. Which makes throttle control easier and more accurate
- Load Cell Pedal: The Brake pedal features high-tech load cell sensors with a 100KG capacity. These sensors detect precise braking pedal pressure, allowing users to achieve the ideal braking force by controlling pressure application
- 16-bit High Precision Magnetic Encoder: The brake and throttle pedals all use 16-bit precision magnetic encoder with 65536 PPR resolution, a much higher resolution and more stable than a Hall sensor
- Detachable Pedal Design: Pedals can be detached and mounted onto other professional brackets with ease. For hardcore users, the pedals can also be reversed. The spacing between 2 pedals is adjustable for optimal comfort
- Realistic Feel: MOZA’s Pit House allows for easy configuration of the pedal output curves according to different needs, replicating the feel of real racing vehicles, enhancing immersion and control
*note: No Clutch- Sold Separately
Made with High-strength Steel
The pedal is machined with high-strength steel, giving superior quality and endurance.
Floor Mounted Organ Type Accelerator Pedal
The organ-type accelerator pedal allows the driver’s foot and pedal to follow the same trajectory. Which makes throttle control easier and more accurate.
High-Precision Load Cell: Maximum Capacity of 100 KG
The MOZA SR-P pedals feature high-tech load cell sensors with a 100KG capacity. These sensors detect precise braking pedal pressure, allowing users to achieve the ideal braking force by controlling pressure application.
16-bit High Precision Magnetic Encoder
The brake, clutch and throttle pedals all use 16-bit precision magnetic encoder with 65536 PPR resolution, a much higher resolution and more stable than a Hall sensor.
*note: No Clutch- Sold Separately
Dual Sensor Fusion Algorithm
The brake utilizes a pressure and angle sensor, allowing fine tuning of braking. The initial stage is dominated by the angle sensor, allowing racers to control the braking angle, the mid and last stage is controlled by the pressure sensor, which makes the pedal easier to control.
Braking Spring and Damping Block Combined
Utilizing both a braking spring and damping block, racers can enjoy more control in the initial stage pedal travel, with a signature stiffness in the final stages of braking, highly simulating a real foot feel.
Springs Damper
Build Your Ultimate Racing Experience
MOZA SR-P Accessory Kit
Order the MOZA SR-P pedal accessory kit to your needs. The accessory kit includes two springs and one damper, together with the spring and damper that come with the pedal set could create six different foot feel combinations. The springs and damping block in the accessory kit can increase dampening and shorten the braking distance, catering to the needs of pro users.
Direct connection with PC through USB
The MOZA SR-P Pedals effortlessly link to your PC via USB and can be easily calibrated using the intuitive MOZA Pit House software. Its universal compatibility with all sim racing gear ensures a smooth and hassle-free experience for all racing enthusiasts.
Pedal Output Curve Adjustment
MOZA’s Pit House allows for easy configuration of the pedal output curves according to different needs.
| Feature | Specification |
|---|---|
| Material (Pedals/Plate) | High-strength steel |
| Brake Sensor | Load cell + angle sensor |
| Max Capacity | 100KG |
| Clutch Sensor | Angle sensor |
| Throttle Sensor | Angle sensor |
| Angle Sensor Resolution | 16-bit (65536ppr) |
| Pedal Spacing | Adjustable |
| Pedal Plate Height | Adjustable |
| Pedal Connection Port | USB |
| Pedal Travel | Yes (Pedal Travel Software Adjustment) |
| Pedal Travel Reverse | Yes |
| Anti-Slipping Pad | Included |
| Size | 410310170 (mm) - Pedal Set of 2 (No clutch) |
| Mass | 4.3KG – Pedal Set of 2 (No clutch) |
